LED Poster Display
Foldable COB LED Poster
As simple as unfolding a poster
Model
- Pixel Pitch (mm)
- 1.25
- White Balance Brightness (nits)
- ≥600(After correction)
- Refresh rate (Hz)
- ≥3840
- Module Weight (Kg)
- 0.5±0.05
01 / 06Overview
As simple as unfolding a poster
This LED poster screen with its ultimate portability, revolutionary setup efficiency, and reliable display quality, is the ideal solution for dynamic visual marketing. It makes setting up a professional large screen as simple as unfolding a poster, helping you create captivating focal points anytime, anywhere.
Specifications
The numbers. Model by model.
Display performance
P1.2- Pixel Structure
- Full Flip-Chip COB
- Pixel Pitch (mm)
- 1.25
- Module Resolution (W*H)
- 256*128
- Unit Area(m²)
- 0.0512
- Pixel Density (pixels/m²)
- 640,000
- White Balance Brightness (nits)
- ≥600(After correction)
- Color Temperature (K)
- 9300 Adjustable
- Viewing Angle (°)
- 160
- Brightness Uniformity
- ≥95%
- Contrast Ratio
- ≥10000:1
- Frame rate (Hz)
- 50&60 Hz
- Refresh rate (Hz)
- ≥3840
Structure & build
P1.2- Module Dimensions (mm) (W*H)
- 320*160
- Module Weight (Kg)
- 0.5±0.05
Power
P1.2- Single module power consumption (W)
- ≤11
- Power supply requirements (V)
- DC: 4.5V
- Single module current (A)
- 2.4A
Operation & certification
P1.2- Typical lifespan (hrs)
- 100,000
- Operating temperature range (°C)
- -10~40°C
- Storage temperature range (°C)
- -20~60°C
- Operating humidity range (RH)
- 10~80% non-condensing
- Storage humidity range (RH)
- 10~85% non-condensing
Specifications depend on the confirmed configuration. Request the full datasheet →
